型号
Model

1092

1575

1880

2100

2400

2800

3000

原纸宽度(mm)
Raw Paper Width(mm)

1350

1750

2100

2300

2500

2850

3000

原纸直径
Raw Paper Dia.

Φ1500mm （请指定）
Φ1500mm   (Other size, please specify.)

原纸纸芯直径
Raw Paper Core Dia.

Φ76 （请指定）
Φ76  (Other size, please specify.)

成品直径
Finished Roll Dia.

Φ40—Φ125mm
Φ40—Φ125mm

退纸架
Unwinding Stand

1-3层，普通链条传动送纸或电机独立送纸（可选）
1-3 ply, ordinary chain transmission or independent motor (optional)

打孔
Perforation

螺旋刀打线
Spiral perforation knife

打孔节距
Perforation pitch

链轮定位
Chain wheel positioning

控制系统
Controller system

PLC控制，变频调速，触摸屏操作
PLC controller,frequency conversion speed regular,touch screen

制品范围
Product range

有芯卷纸，无芯卷纸
Core roll of paper , coreless roll of paper

落管
Core Drop

手动，自动（可选）
Manual ,automatic (optional)

无芯卷纸
Coreless roll

自动抽芯
Automatic shaft drawing

生产速度
Production Speed

150—200米/分钟
150-200m/min

喷胶、切断及收卷
Tail trimming and sealing

自动
Automatic

成品推出
Finished Product Output

自动
Automatic

操作方式
Operation type

遥控器操作
Remote control

电源配置
Power

380V, 50HZ
380V, 50HZ

所需气压
Air pressure required

0.5Mps（需方自备）
0.5Mps (Prepared by user)

可选配置
Optional

压花
Embossing

单压花，双压花（钢辊对羊毛辊、钢辊、毛布辊），可选
Single/double embossing(steel to wool/steel/felt roller)(Optional)

压边纹
Edge embossing

气缸控制，钢对钢结构
Cylinder control,steel to steel structure
