技术参数Technical Parameters:

型号
Model

单层：Single deck
双层：double deck

原纸宽度（mm）
Raw Paper Width (mm)

190—800mm （规格请指定)
190—800mm  (Please specify your size)

原纸芯直径
Raw paper Core Dia

Φ76mm （规格请指定)
Φ76mm  (Please specify your size)

原纸直径
Raw Paper Dia.

Φ1000—Φ1500mm
Φ1000—Φ1500mm

折叠规格
Fold Type

1/4  1/6  1/8折
1/4  1/6  1/8 fold

产品规格
Finished Product Size

190—400mm （可选）
190—400mm (Other size, please specify.)

设计车速
Design Speed

250米/分钟
250m/min

生产速度
Production Speed

160—220米/分钟（印刷与无印刷速度不同）
160—220m/min (Production speed with printing unit is different  from that without printing unit.)

电源配置
Power

AC380V 50HZ
AC380V 50HZ

所需气压
Air Supply

0.5Mpa
0.5Mpa

选配项
Options(To order)

印刷装置
Printing Unit

柔版印刷，敞开式或封闭式印刷（可选）
Flexo printing unit, open ink tank printing unit or sealed doctor blade for printing ( please specify.)

压光装置
Calendering Unit

钢对钢，钢对胶
Steel to steel, steel to rubber
